OKM eXp 4500 Light

OKM multifunctional surface detection detector - with limited characteristics

Cases: Treasure hunting, natural gold search, cavity detection, and so on: cavity measurement Depth: customers found objects 25 m deep.

Operating modes: ground scan, mineral scan, pinpointer.

Objects detectable: trunk, hole, tunnels.

FEATURES

3D Visualization

3D Ground Scan

Exchangeable probes

GST / EMSR

Internal memory

Live Sound

Mineral Scan

Multilingual operation

Rechargeable high-capacity battery

Speaker

DESCRIPTION

 3D Treasure Hunting and Gold Prospection Ground Scanner

Ground scans such as eXp 4500 can detect buried depth depths that common metal detectors cannot reach, allowing treasures hunters of all levels – entrance, experienced and professional users. The multifunctional treasure detector can find old relics, lost treasures and minerals made of natural gold.

eXp 4500 Special Features at a Glance

eXp 4500 Ground Scan

non-intrusive real-time ground surveying before excavating

quick and easy setup and operation

exchangeable probes of various purposes

color-coded surveys

immediate on-site interpretation of target area

measured values show extreme depth of survey

measured values show location of targets within surveyed area

highly sensitive and accurate metal detection

DELIVERY SCOPE

1x        Control unit

1x        Super Sensor

1x        Software Visualizer 3D Studio Standard Edition with data cable

1x        Waterproof and shock resistant Pelican case

1x        Bluetooth headphones

1x        Joystick

1x        Power Pack with charger and travel adapter

1x        Quick Start Guide

Specifications

Control unit

Dimensions (H x W x D): 70 x 140 x 300 mm

Weight: approx. 1530 g

Input voltage: 12 – 14.4 V DC, 22 W max

Display: 1000 mcd Background lighting, 6.5" Diagonal, 640 x 480 Pixel TFT, Color, Anti-Glare

Processor: AMD-GX, Dual-Core 1 GHz Processor, GPU 300 MHz

Working memory (RAM): 2 GB

Data memory: 8 GB

Operating temperature: 0°C – 40°C

Storage temperature: –20°C – 60°C

Waterproof: No

Operating time: approx. 3 hours (full charged Power Pack, 25°C)

Air humidity: 5% – 75%

Protection Type: IP 40

Feedback: acoustic, visual

Data transmission

Technology: USB

Maximum Transfer Rate: 115200 Baud

Computer minimum requirements

CD-ROM drive: minimum 4x

Interface (Data transmission): USB

Free disk space: minimum 50 MB

Working memory (RAM): minimum 256 MB

Graphic card: minimum 128 MB, OpenGL-compatible

Processor: minimum 1.2 GHz

Operating system: Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10

The technical data are average values. Minor deviations are possible during operation.
